Dometic DF Series Service Manual

12
EN
Furnaces
AC Models
8
Limit Switch
Sail Switch
Valve
ON/OFF
Switch
Electrode
Motor
Capacitor
Transformer
Ignition
Control
Blue
Blue
Red
Red
Red
Blue
Thermostat Thermostat
Ground
120 VAC Hot
120 VAC Neutral
Blue
Blue
Black
Brown
Black
Black
Yellow
Green
Green
Green
White
White
White
White
Green
Green
Yellow
24 VAC
9
120 VAC input
120 VAC
(Older Models)
Circuit Breaker or
Breaker/Switch
Combination
ON/OFF Switch
Option
Ignition Control
Electrode
Limit
Switch
Sail Switch
Relay
Motor
Valve
Transformer
Thermostat
Capacitor
