 EN
Typical placement of mounting brackets and condensate drains -
7
1
2
1 Condensate drain hose barb 2
Mounting bracket
Condensate drain installation for Turbo and Voyager -
8
2
3
4
5
1
1 Hose barb 4 Drain pan
2 Threaded drain hole 5 Drain hose
11
