Installation FreshWell3000
8
• Place the assembly template into the chosen compartment and check the space
available for the openings in the floor.
• To minimize the transmission of noise and vibration during operation, the under-
bench air conditioner should have a all around minimum clearance of 30 mm to
walls and furniture.
• The under-bench air conditioner must be installed on the floor.
• Keep a distance of 200 mm between the front of the under-bench air conditioner
and the walls of the compartment to facilitate filter replacement.
• Installing the under-bench air conditioner into an external compartment (e.g.
false bottoms), the air to be treated must be drawn in from the vehicle’s
passenger compartment.
• Suctioning of outside air can significantly reduce the power of the system.
Note on electrical system (see fig. c)
• Only a qualified electrician should connect the under-bench air conditioner to
the electrical power.
• Check that the voltage specification on the type plate is the same as that of the
power supply.
• Do not lay cables which are loose or bent next to electrically conductive material
(metal).
No. in fig. c Description
1 Motor ventilator (inner)
2 Motor ventilator (outer)
3 Capacitor
4 Compressor
5 Temperature sensor
6PCB
7PCB display
8 PCB interface
9 Soft start
10 Valve
11 Resistor
