Installation FreshWell3000
10
7.5 Installing the external grids
See fig. 8
➤ Fasten the external grids as shown with the screws and washers included in the
supply.
7.6 Installing the receiver
See fig. 9
➤ Drill an opening of 50 mm into the wall.
See fig. 0
➤ Lay the cable through the hole to the under-bench air conditioner.
➤ Fasten the receiver as shown.
7.7 Laying the connecting cables
D
The under-bench air conditioner must be connected to an electric circuit which is
able to supply the required current (see chapter “Technical data” on page 15).
➤ Select the cross-section of the cable corresponding to the length:
– Length < 7.5m: 1.5mm²
–Length > 7.5m: 2.5mm²
See fig. a
➤ Plug the four-pole plug of the receiver into the IR socket of the (1).
➤ Plug the 230 Vw plug into an 230 Vw socket (2).
7.8 Air ducting
See fig. b
Make the air ducting (1) with trade parts (not included in the supply). It is recom-
mended to use cardboard pipe for air conditioning with an aluminium core and
external covering of PVC. The nominal inside diameter should size up to 60 mm, the
outside diameter 65 mm.
DANGER! Danger of electrocution
Make sure there is no voltage at electrically operated components
before carrying out work on them!
FreshWell3000-I-16s.book Seite 10 Mittwoch, 12. Dezember 2018 2:11 14
