8.3 SOC INDICATION
SYMBOL BATTERY VOLTAGE
≥ 12.8 / 25.6 V
≥ 12.6 / 25.2 V to 12.8 / 25.6 V
≥ 11.8 / 23.6 V to 12.6 / 25.2 V
≥ 11.0 / 22.0 V to 11.8 / 23.6 V
≤ 11.0 / 22.0 V
Note there are two different system voltages that can be supported: 12V and 24V. If the voltage read from the controller is less
than 18V the system voltage shall be 12V. If the voltage is greater than 18V the system voltage shall be 24V.
BLUETOOTH
®
WIRELESS TECHNOLOGY
