Dometic Hipro Alpha A 30S1 - Technical Specifications; A30;A40 Series Data

EN
Technical data HiPro
20
12 Technical data
For the current EU declaration of conformity for your device please refer to the
respective product page on dometic.com or contact the manufacturer directly
(see dometic.com/dealer).
Further product information can be accessed via QR code on the energy label in the
figures or via eprel.ec.europa.eu.
HiPro
A30S1, A30S2, A30P1,
A30P2, A30G1, A30G2
HiPro
A40S1, A40S2, A40P1,
A40P2, A40G1, A40G2
Input voltage: 220 – 240 Vw
50/60 Hz
Total volume: 26 l 33 l
Rated input power: 60 – 70 W
Climate class and intended
ambient temperature use:
N: +10 °C to +32 °C
T: +16 °C to +43 °C
Noise emission: 0 dB(A)
Refrigerant: R717
Dimensions (W x H x D): 384 x 520 x 446 mm 405 x 550 x 466 mm
Weight:
With solid door:
With panel door:
With glass door:
13.7 kg
15.0 kg
15.9 kg
15.3 kg
16.7 kg
17.9 kg
Test/certificates:
