Technical description M55LX AHD, M75LX AHD
14
51.Switches the menu on.
2. Calls up the parameters for setting.
The parameters are distributed over four screen pages in the
following order:
Page 1: Picture
–Brightness
–Contrast
–Colour
–Volume
–Auto Dim
– Distance: Distance marker setting
Page 2: Options
– Language: German, English, French, Italian, Dutch, Spanish,
Portuguese, Russian
– Scale: switches the distance markers on or off
– Camera 1/Camera 2/Camera 3/Camera 4: Normal or
Mirrored
– Sensitivity: Setting of the switching threshold for the night
dimmer function
– Trailer detection ON/OFF: Shortens the activation time in
OFF mode
Page 3: Auto search
– Automatic search Switches the automatic camera panning on
(the cameras are activated in preset time intervals, e.g. for
horse transporters with multi-box monitoring).
– Camera 1/Camera 2/Camera 3/Camera 4: Setting for the
switching intervals
– Reset (“Default”): Default setting for all parameters
6 CAM Switches from one camera to the next.
7Monitor bracket
8 Loudspeaker
No. in
fig. 0,
page 6
Descrip-
tion
Description
M55LX-AHD-M75LX-AHD-IO-16s.book Seite 14 Montag, 17. Dezember 2018 3:56 15
