M55LX AHD, M75LX AHD Installing the LCD monitor
15
7 Installing the LCD monitor
7.1 Tools required (fig. 1, page 3)
For installation and assembly you will need the following tools:
•
Measuring ruler (4)
•
Centre punch (5)
•
Hammer (6)
•
Drill head set (7)
•
Drill (8)
•
Screwdriver (9)
To establish and test the electrical connection, the following tools are required:
•
Diode test lamp (1) or voltmeter (2)
•
Insulating tape (10)
•
Heat shrinking sleeve
•
Hot air blower (11)
•
Crimping tool (12)
•
Soldering iron (optional) (13)
•
Solder (optional) (14)
•
Cable bushing sleeves (optional)
To fasten the cables, you may require additional cable binders.
7.2 Installing the monitor
!
Observe the following installation instructions:
•
Select an installation location that provides an unobstructed view of the monitor (fig. 6 and
fig. 7, page 4).
•
Never install the monitor in areas where your head could hit it or in the airbag deployment path.
This could cause injury if the airbag opens.
•
The monitor must not impair your vision when driving (fig. 8, page 5).
•
The installation location should be flat.
•
Check that there is sufficient space underneath the installation location to attach the washers
and nuts.
CAUTION! Beware of injury
Select the location of the monitor so that it cannot injure the passengers in the vehicle
under any circumstances (e.g. sudden braking, road traffic accidents).
