Using the LCD monitor M55LX AHD, M75LX AHD
18
I
➤ If the monitor is to be activated e.g. when the indicator is flashing, connect the following
control cable to a positive cable of the indicator:
–white cable (8), blue cable (13)
I
This control cable is used as a signal cable for the activation of a side camera when an indicator is
flashing, for example.
➤ If necessary, connect the CAM1 socket (9) of the connection cable to the plug of video source
1 (e.g. reversing camera).
➤ If necessary, connect the CAM2 socket (10) of the connection cable to the plug of the video
source 2 (e.g. side camera).
➤ If necessary, connect the CAM3 socket (11) of the connection cable to the plug of video source
3 (e.g. camera).
I
Connecting an additional reversing camera (trailer operation)
➤ If necessary, connect socket CAM4 (12) of the connection cable to the plug of the additional
reversing camera.
8 Using the LCD monitor
8.1 Switching on the monitor
➤ If the monitor is switched off, press the P button (fig. 0 2, page 6) to switch the monitor on.
➤ The button lights up green.
✓ The picture appears.
8.2 Switching off the monitor
➤ Press the P button (fig. 0 2, page 6) to switch off the monitor.
➤ The button lights up red.
✓ The picture disappears.
NOTE
If voltage is present in the green cable (7), the reversing camera will be activated
automatically. The reversing camera has priority.
NOTE
If voltage is present in this control cable, the video input CAM2 and CAM3 will be
activated.
NOTE
Observe the power consumption of the video system. The cameras are equipped with
heaters. A maximum current of 1.5 A can flow (three cameras in heating mode). Use a
disconnector switch for direct connection to the battery. This allows you to disconnect
the video system from the battery easily if you are no longer using the vehicle.
