Installing the LCD monitor M55LX AHD, M75LX AHD
16
•
Check beforehand that there is sufficient space on the other side for the drill head to come out
(fig. 2, page 4).
•
Bear in mind the weight of the monitor. Provide reinforcement if necessary (larger washers or
plates).
•
Make sure you can lay the connection cable to the monitor.
Choosing the installation location (fig. a, page 7)
➤ Place the monitor on the monitor bracket.
➤ Position the monitor and the attached monitor bracket provisionally.
➤ Mark the outlines of the corners of the support base on the dashboard.
➤ Take the monitor off the monitor bracket.
Screwing the monitor bracket onto the dashboard (fig. b, page 7)
➤ Hold the support base within the outlines marked beforehand.
➤ Fasten the monitor bracket with the self-tapping screws.
Fastening the monitor
➤ Set the monitor on the monitor bracket and secure it with the knurled nut (fig. a, page 7).
➤ Slide the cover over the monitor bracket on the monitor.
7.3 Connecting the monitor electrically
The circuit diagram for the LCD monitor can be found in fig. d, page 8:
No. Description
1Monitor
220-pin socket
3 Monitor line
4 20-pin plug
5 12 – 24 V positive cable (red): connected to the positive pole of the ignition
(connected positive, terminal 5) or the positive pole of the battery
(terminal 30).
6 Earth cable (black): connected to the negative pole of the voltage source.
7 Cable (green): control input for video input CAM1,
such as for connecting the reversing light
8 Cable (white): control input for video input CAM2,
such as for the side camera
9 6-pin CAM1 socket (connection to video source 1)
10 6-pin CAM2 socket (connection to video source 2)
