MSG150 Accessories/expansions
13
4 Accessories/expansions
5Intended use
MagicSafe MSG150 (ref. no. 9600000368) is a gas detector which detects noxious gases before
they can take effect. MSG150 has been designed for use in vehicles to detect noxious gases which
have an ether, chloroform, butane, ethane or trichloroethane basis.
I
6 Technical description
The MSG150 gas detector can be used as a warning device in many areas to detect gases with a
narcotic effect before they can take effect.
The gas detector contains a sensor and an acoustic signal generator and is connected to a
12/24 Vg voltage supply, e.g. the cigarette lighter in a vehicle.
In addition to this, the gas detector contains an internal relay. An external siren of signal lamp can
be connected to this.
The connection terminal for the relay connection can be found on the back of the gas detector
(fig. 3, page 4).
You can operate the gas detector in three ways:
• As single device
• In combination with the external siren (ref. no. 9101600008)
• In combination with the MagicSafe alarm system MS660 or DVS90
Description Ref. no.
External siren 9101600008
Additional switch RV-AMP-SW
NOTE
With a voltage range of 10 to 32 Vg, the gas detector is suitable for use in both cars
and trucks.
No. in
fig. 3,
page 4
Description
1 Relay contact 1
2 Relay contact 2
MSG150-IO-16s.book Seite 13 Donnerstag, 11. August 2016 12:02 12
