Mounting the MagicSafe MSG150 MSG150
14
7 Mounting the MagicSafe MSG150
7.1 Tools required
For mounting you will require the following tools:
• Measuring ruler (fig. 1 1, page 3)
• Centre punch (fig. 1 2, page 3)
• Hammer (fig. 1 3, page 3)
• Drill bit set (fig. 1 4, page 3)
• Electric drill (fig. 1 5, page 3)
• Screwdriver (fig. 1 6, page 3)
7.2 Mounting the gas detector
Note the following when selecting a place to fit the gas detector:
• Note the length of the cable.
• The gas detector should be mounted in the vicinity of the sleeping area at the height of the
mattress.
➤ Select a suitable installation location.
A
➤ Hold the mounting panel on the chosen location and mark the two drill holes (fig. 5 , page 5).
➤ Screw the mounting panel tight with the two self-tapping screws (fig. 6, page 5).
➤ Insert the gas detector on the mounting panel (fig. 7, page 5).
➤ Insert the plug of the gas detector in the socket of your 12/24 Vg voltage supply.
✓ The green LED on the gas detector (fig. 8 1, page 5) flashes for approx. 10 min. The sensor is
then brought to the operating temperature.
When the green LED glows constantly, the gas detector is ready for operation.
8 Connecting the gas detector
8.1 As a single device
If you use the gas detector as a single device, you can either
• Switch it on with the 12/24 Vg plug
• Switch it on with the RV-AMP-SW additional switch (accessory), if there is no 12/24 Vg socket
in the sleeping area.
NOTICE!
Before making any drill holes, ensure that no electrical cables or other parts can be
damaged by drilling.
MSG150-IO-16s.book Seite 14 Donnerstag, 11. August 2016 12:02 12
