6
Dometic MasterFlush Toilet Components / Installation
5 Components (g.
1
, page 2)
Ref. Description
A Toilet seat
B Toilet bowl
C Toilet base
D Flush pedal
E Water valve
F Macerator pump
G Floor ange seal
Ref. Description
H Electrical wires
I Vacuum breaker cover
J Vacuum breaker
K Pump/base cover
L Floor ange mounting hardware
kit
NS Remote mounting hardware kit
6 Installation
Note
Be sure foot pedal, when pressed, touches same at surface on which toilet is installed.
Note
Be sure to follow recommended installation requirements in section 4.2 of this manual.
NOT INTENDED FOR INSTALLATION IN A SHOWER.
6.1 Tools required
• pliers or adjustable wrench
• 7/16-in. / 11 mm wrench
• electrical connection tools
6.2 Installation on floor flange
1. To replace an older toilet, turn off water supply to toilet. Remove and drain water supply line.
Remove toilet hold-down bolts/screws. Remove toilet from oor. Remove and discard old
oor ange seal and hold-down bolts. Verify center of oor ange is at least the recommended
rough-in distance from back wall (g.
3
A, p. 2). See Rough-in dimensions. Make sure top
surface of oor ange is clean and free of any debris or sealant.
2. If installing a new oor ange, make certain that toilet mounting holes are at the correct
location (g.
3
D, p. 2). Floor ange must be secured to oor with a minimum of four screws
(8 is preferred). Insert two supplied T-bolts into slots in oor ange (g.
4
p. 2).
3. Verify that oor ange seal is installed on base of toilet (g.
5
A, p. 2). Carefully set toilet over
oor ange. Align holes in toilet base with T-bolts as toilet is lowered onto oor ange. Toilet
must be aligned so that outlet of base ts inside of oor ange outlet hole.
Note
Entire toilet base does not rest completely on oor yet. Floor seal must be compressed in
following steps.
Please refer to complete parts list (printed separately)
for more details.
