EN
Model Air pressure Water flow Condensate water
AP3 440 Pa 504 L/h 19.5 kPa 1.3 L/h
AP5
AP5 SLIM
430 Pa 684 L/h 8.5 kPa 1.55 L/h
AP8
AP8 SLIM
440 Pa 720 L/h 10.5 kPa 2.1 L/h
AP10 580 Pa 1116 L/h 12 kPa 2.45 L/h
AP12 570 Pa 1476 L/h 2.75 L/h
TWIN12 440 Pa 756 L/h 2.5 L/h
TWIN18 560 Pa 1116 L/h
14.5 kPa
3.2 L/h
Pipe connection
Fan coil Pipe fitting di-
ameter
Copper pipe thread identification Pipe connector
MINI
COMPACT
JUNIOR
GIANT4
½"-14 NPT A
GIANT8 ½"-12 NPT B
APM
AP1
AP3
AP5
A
AP8
½"-14 NPT
C
AP10 B
AP12 C
TWIN12K B
TWIN18K
16 mm
½"-14 NPT
C
Table 1: Legend
No. Description
A Screw connection
B Vent valve with integral bypass configurations and on-off type electric actuators
C Vent valve
Fan coil dimensions
NOTE Fan coil dimensions with vent valve and without condensation drip pan.
30
