Dometic RCD10.5XES User Manual

Installation RCD10.5XES
EN
14
8.3 Installation with one lower rear vent and one roof vent
1. Install the lower air vent LS300 flush to the vehicle floor.
2. Install a roof vent instead of a rear upper air outlet vent.
– Install the roof vent (fig. 4 2) directly above the back of the refrigerator as far as this is possible.
– If needed use an air duct to install the roof vent offset, otherwise heat will accumulate there.
No. in fig. 4, page 14 Description
1 LS300 ventilation grille
2 Roof vent
2
1
10 – 25 mm
4
