Dometic RCD10.5XES - Ventilation Grille Mounting

Installation RCD10.5XES
EN
16
8.6 Installing the ventilation grille
1. Make a cut out in the wall to fit an appropriate upper and lower vent system, choose LS300 check the dimen-
sions required for the vent. See chapter “Installation location” on page 11.
No. in fig. 6, page 16 Description
1 Slider
2 Ventilation grille
3 Installation frame
3
2
1
4
6
