4.2 Installing the compressor unit (RC 10.4M.90)
The compressor unit is removable and can be mounted apart from the refrigerator.
Installation location
Observe the following instructions when selecting an installation location for the
compressor unit:
• Choose a location for the compressor unit at a maximum distance of 1.5 m from
the refrigerator.
• Prepare a closed duct. The duct must be at one end open and equipped with a
ventilation grille.
• Ensure that the ventilation grille has a free cross-section of at least 60 cm
2
.
• Note the following maximum dimensions of the duct (fig. 4, page 5):
Recess width (W) 425 mm 425 mm
Recess depth (D) 598 mm 598 mm
RCS10.5(S)(T) RCS10.5X(S)(T)
Refrigerator height (A) 821 mm 821 mm
Refrigerator width (B) 523 mm 523 mm
Refrigerator depth (C)
(excludes control knob 5 mm)
555 mm 610 mm
Recess height (H) 829 mm 829 mm
Recess width (W) 528 mm 528 mm
Recess depth (D) 558 mm 613 mm
Compressor unit Duct
Height A 169 mm H 177 mm
Width B 185 mm W 190 mm
Depth C 396 mm D 400 mm
RCL10.4(S)(T) RCL10.4E(S)(T)
