13. INSTALLATION OF DECORATIVE
DOOR PANEL
The door panel can easily be mounted. The dimensions
of the panel must be:
Height 19-3/4"
Width 17-27/32"
Thickness Up to 1/8"
Weight 49 lbs.
A. Remove the door. See Section 12.
B. Remove the lower trim molding. (NOTE: Trim molding
is not installed on new units in cartons)
C. Fit the new panel in place and slide it up as far as
possible.
D. Fit the trim molding back in place.
SECTION B. CERTIFIED VENT SYSTEMS
SECTION C. OPERATING INSTRUCTIONS
1. IMPORTANCE OF LEVELING A
REFRIGERATOR
In an absorption refrigerator system, ammonia is lique-
fied in the finned condenser coil at the top of the refrige-
rator. The liquid ammonia then flows into the evaporator
(inside the freezer section) and is exposed to a circula-
ting flow of hydrogen gas, which causes the ammonia to
evaporate, creating a cold condition in the freezer.
The tubing in the evaporator section is specifically slo-
ped to provide a continuous movement of liquid ammo-
nia downward by gravity through this section. If the
refrigerator is operated when it is not level and the
vehicle is not moving, liquid ammonia will accumulate in
sections of the evaporator tubing. This will slow the cir-
culation of hydrogen and ammonia gas, or in severe
cases, completely block it, resulting in a loss of cooling.
Remember to level the vehicle when stopping for more
than an hour, otherwise the cooling unit could be perma-
nently damaged due to overheating if it is left "ON".
When the vehicle is moving, the leveling is not critical as
the rolling and pitching motion of the vehicle will pass to
either side of level, keeping the liquid ammonia from
accumulating in the evaporator tubing.
7
VENT KIT OPTIONS COMPONENTS PART NO.
DUAL METAL SIDE * RM 123 Upper Metal Side Vent 3100451.024
VENTS * RM 183 Lower Metal Side Vent 8030211.332
** Power Ventilator Optional 3108705.751
UPPER METAL SIDE VENT * RM 123 Upper Metal Side Vent 3100451.024
LOWER PLASTIC SIDE VENT * Lower Plastic Side Vent 3107560.009
** Power Ventilator, Optional 3108705.751
DUAL PLASTIC SIDE * Upper Plastic Side Vent 3107560.041
VENTS * Lower Plastic Side Vent 3107560.009
** Power Ventilator Optional 3108705.751
* Vent System requires one each.
** Alternative instructions forwarded with ventilator kit. Used in conjunction with
upper and lower side vents at minimum vent heights for optimum performance.
