APPENDIX B - REARVIEW EQUIPMENT
Power module
Flexible cord
12 volt
D+
Terminal block
Drain water hose
Inlet fitting
Manual gas
shutoff valve
Burner jet
Screw for protection cover
Protection
cover
Flue baffle
Heater
Thermofuse
385 13 31−01
5
12V DC
HVT
J2
J3
J1
F4 (5A)
F3 (5A)
SWITCHED
12V
LAMP
TEST
LINE
AC HTR
LINE
AC HTR
NEUT
NEUT
