Dometic RM 5310 Installation Instructions

11
Installation
Fig. 12
Fig. 11
Fig. 13
1
1
2
2
installation recess above the refrigerator. Affix
the this plate to the caravan wall, do NOT
attach to the refrigerator !
Attach the deflector plate so that the heated
air escapes through the top ventilation grill into
the open air and no heat build-up can be pro-
duced.
The refrigerator is later pushed into the instal-
lation recess from the front. Ensure that the
seals abut the case evenly.
This installation option facilitates the removal
and installation of the appliance for servicing.
The cavity in-between the outer vehicle wall
and refrigerator is completely isolated from the
vehicle interior. Intrusion of exhaust fumes into
the living space is prevented. Fumes will esca-
pe through the upper ventilation grille to the
outside.
Fig. 14/15
Fasten the sealing lips to a stop bar on the
rear side (1), e.g. by gluing.
1
Proposal 2
Deviations require the consent of the
manufacturer!

Dometic RM 5310 Specifications

General

Climate class	SN
Total net capacity	55 L
Total gross capacity	60 L
Minimum operating temperature	10 °C
Lamp type	LED
Fridge net capacity	50 L
Fridge interior light	Yes
Number of vegetable drawers	-
Freezer position	Top-placed
Freezing capacity	- kg/24h
Freezer net capacity	5 L
Storage time during power failure	- h
Current	0.54 A
Power source	Gas/Electric
Connected load	125 W
Gas consumption	270 g/24h
AC input voltage	230 - 240 V
AC input frequency	50 - 60 Hz
Door hinge	Left
Control type	Rotary
Product color	Black, Grey
Appliance placement	Freestanding
Refrigerating medium	R717
Package depth	543 mm
Package width	523 mm
Package height	635 mm
Package weight	24000 g

Weight and Dimensions

Depth	474 mm
Width	486 mm
Height	618 mm
Weight	20000 g
