Dometic RM 7271 L User Manual

13
ert
5.10
1. Open the door
and loosen the
hinge screw.
2. Take off the door
by moving it
upwards.
3. Unscrew the door strip
(3 screws).
4. Remove the decor
plate and insert a
new decor plate.
5. Screw the door
strip back in
position.
6. Put the door
back on.
7. Tighten the
hinge screw.
5.11
RM 7271 /..75 730+1 453,5+1 3,2
RM 7361 /..65 730+1 453,5+1 3,2
RM 7371 730+1 453,5+1 3,2
RM 7291 /..95 730+1 491,5+1 3,2
RM 7401 /..05 730+1 491,5+1 3,2
RM 7541 /..45 730+1 491,5+1 3,2
RM 7551 /..55 738+/-1 498,5+1 3,0
Model Height Width Thickness
Interior light
Changing the LED lighting
Changing the decor panel
1. Remove cover
4. Insert new lighting.
2. Loosen and detach
housing
3. Connect new LED-
lighting. Observe polarity.
+
-
Please contact Dometic Service Centres for replacement LED-lighting.
Dimensions of the panels in mm:
