INSTRUCTIONS FOR MOUNTING .THE DOOR PANEL
The
refrigerator
is
normally
delivered without
door
panel(s).
Before starting the
mounting
work check that the panel
dimen-
sions are in compliance wiyh those given in the table and read the
instructions through. When mounting the panel, proceed as
follows.
A.
B.
C.
D.
E.
F.
Remove the top decoration strip (2) with its two screws
(1).
Insert one of the vertical edges of
the
panel into the groove
of the door frame (3).
Bend the panel gently so that the free side of the panel can
be slipped into the
corresponding
groove of the door
frame
(4).
Push the panel downwards so that the lower horizontal
edge of the panel is fitted into the bottom groove (5).
Between the upper edge of the panel and the door frame
there is now a gap whii should be covered by the decora-
tion strip.
Put the strip across the door so that the gap is covered and
push it upwards (6).
The tabs on the inside of the strip
should
fit in behind the
flange of the door frame. Secure the decoration strip by
means of the two screws (1).
Panel dimensions
Thickness max.
5/32"
HEIGHT
WIDTH
TYPE
MAX. MIN.
MAX. MIN.
RM763
296 293
569
566
11 21/32' 11 17/32" 22 13/32" 29 9/32"
iz
RM763
809
806
566
31 27/32" 31 23/32" 22 13/32" 22 9/32"
itit
RM1303
369
366 618
615
14 17/32"
14 13/32"
24 11/32"
24 7/32"
s
RM1303
888
885
618
615
lower
35" 34 27/32" 24 11/32" 24 7/32"
