FAULT TRACING
The refrigerator does not freeze
satisfactorily
Causes and remedies
a)
b)
c)
d)
e)
f)
:;
i)
j)
Jet orifice clogged. Unscrew jet and blow dear or wash in
alcohol. Do not use
wire
or pin to clean orifice.
Check
the leveling of the refrigerator.
Air circulation around cooling unit is restricted. Be sure that
refrigerator is property ventilated.
The evaporator is
heavily coated with frost. Defrost.
Flue
baffle
not inserted into
the central tube of the cooling
unit.
The
thermostat is
incorrectly
used.
See
paragraph on ther-
mostat.
Burner
head
clogged.
Clean.
Burner
damaged. Replace. See fig. 2.
Bumer may
be
dislocated.
Relocate.
Wrong gas pressure at the
burner.
Have pressure checked at
bumer and
at gas bottle.
Pressure
at
burner
must not
fall
below
11
“W.G.
ODOR FROM FUMES
Causes and remedies
a.
The
flame touches side of the boiler due to dislocation of the
burner. Relocate. Burner dislocation may also cause smoke
and discoloring of walls and ceiling.
b. Burner damaged. Replace.
c.
The flue tube is dirty. Clean flue as follows: Cover burner and
jet. Remove flue top and baffle. Clean flue with special flue
brush. Clean baffle before putting back in place.
All the above instructions are to be followed closely. The
refrigerator is
quality-guaranteed.
However, we are not respon-
sible
for any failures caused by improper adjustments and
unfavorable installation
conditions.
Contact service point or dis-
tributor service dept. for assistance.
Replacement Parts Suppliers: See cover.
