CERTIFIED INSTALLATION
Certified installations require one roof vent and one lower side
vent.
Certified vent system kits, see separate list.
For further information contact your dealer or distributor.
METHODS OF INSTALLATION
The
methods of installation are shown in figure 10.
It is essential that all maximum or minimum dimensions are
strictly maintained as the performance of the refrigerator is
dependent on an adequate flow of air over the rear of the
refrigerator.
VENTlLATlON
HEIGHTS
Installation with roof
vent and tower side vent
Refrigerator
Minimum
ventilation
heights in inches
RM763
56
RM1303
62
CLEARANCES
Minimum clearances
in inches to combustible materials are
G: Top
0
K: Side 0
L: Bottom 0
M: Rear 1
Clearance
M
between the
rearmost
part of the refrigerator and
the wall behind the refrigerator.
Clearance N on top of the condenser is related to the minimum
ventilation height.
See Fig
11,12
and examples below
Fig.
11
Refrigerator
Overall Installation
Recess Distance between
model
dimesions
dimensions
dimensions
top of condenser to
top of refrigerator
Height
Width
Depth Height
Width
Depth
Height
Widteh
Depth
A
B C H
W
D
H
W
D
E
RM763
52 23 2411/16 51
-3/16 21 9/16 22-3/4 51-3/8 21-13/16 23-3/4 1/8
RM1303
57-15/166 24-15/16 24-
11/166
57
1/4 23 7/16 22-3/4 57-1/2 23-13/16 23-3/4 1/8
Condenser
This method of installation and these
clearancess
will give you adequate space for servicing and for proper operation.
EXAMPLES
N=Minimum ventilation height 56 minus installation
height
The clearance N for the
RM763
model is derived at in the
follow-
ing way
51
3/16
plus
distance between condenser top and refrigerator top
1/8 plus
distance between roof surface and roof vent cap 5
1/4
N=56-51
3/16+1/8+5
1/4=10
-3/16
Installation with roof vent and lower side vent
Fig. 12
6
