- 11 -
STARTING THE REFRIGERATOR
1. Check that all the manual gas valves are in the
ON position.
2. Make sure that a continuous 12 VDC supply is
available for the electronic control to function.
3. Press the ON/OFF button.
4. Select operation mode:
- AUTO mode (AC and LP gas)
Press the AUTO/GAS mode selector button
(if not already on).
- GAS mode (LP gas operation only)
Press the AUTO/GAS mode selector button
to turn off the AUTO mode (if not already off).
ADJUSTING THE THERMOSTAT
The adjustable thermostat ranges from 1 - 5 (5 = coldest
temperature setting).
After the initial start-up, adjust the thermostat by
pressing the TEMP. SET button repeatedly until
the desired setting is displayed.
The thermostat controls both the gas and electric opera-
tion. Thus, it is not necessary to reset each time a differ-
ent energy source is employed.
INSTRUCTIONS FOR USE
OPERATING THE ICE MAKER
RM1350IM, RM1350MIM, RM1350WIM & RM1350WID
Before the ice maker can operate, make sure that:
The refrigerator is connected to 120 VAC .
The water valve supplying the refrigerator is turned on.
The ice level bail arm is in its fully down position.
When the ice maker thermostat senses the preset tempera-
ture for the ejection of the ice cubes, the ngers will start to
rotate, dumping any ice cubes and lling the mold with water.
When the storage container is full, the bail arm will come
in contact with the ice cubes. The bail arm cannot return
to the full down position and the ice production is stopped
until the bin is emptied, or ice cubes are removed.
To prevent water from splashing out of the mold assembly
while travelling in your recreational vehicle, raise the bail
arm to the full UP/OFF position about 1-1/2 hours before
departing. This will allow the water in the mold to freeze.
WATER SUPPLY
The water supply system must have a minimum pres-
sure of 15 pounds per square inch gauge (psig). A 1/4"
diameter water line to the water valve should be used at
the rear of the refrigerator. The water line must have a
manual shutoff valve placed where it is easily accessible.
The maximum water level is represented by a thin line. It
is essential that the water level does not exceed this line!
If necessary,change the water ow by adjusting the water
supply. For instructions, see ADJUSTING THE SIZE OF
CUBES.
LP GAS EQUIPMENT ASSEMBLY
BURNER TUBE .
SPARK ELECTRODE
BURNER JET
BURNER MOUNTING
SCREWS
PRESSURE TEST PORT
MANUAL SHUTOFF VALVE
Shown in open position
INLET FITTING
SOLENOID VALVE
Maximum
water level
Ice level
bail arm
Down
position
FIRE HAZARD. When the RV has not been
used for some time, make sure that the path
between the burner jet and the burner tube
has not been obstructed before lighting the
LP gas burner. Failure to obey this warning
could cause a re resulting in death or seri-
ous injury.
