When installing the refrigerators full consideration should be taken to the sealing
instructions and the specified minimum clearances and ventilation heights tabled
below:
MINIMUM INSTALLATION CLEARANCES IN INCHES
Figure showing
location of the
clearances
the
Fig. 3
Clearances on
sides,
top and
bottom
Clearance A from
the rear of storage
compartment
Clearance B from
rear of
condenser
Clearance C on
top of
condenser
Refrigerator model
1
RM66
RM76
RM67
RM77
See minimum ventilation
height figures
Kit No. 1
- RM24
comprising:
Upper side vent (Dometic 123)
Lower side vent
(Dometic 183)
(see Fig. 4)
MINIMUM VENTILATION HEIGHT FIGURES
Refrigerator
Installation type
model Kit No, 1
Kit No. 2
Kit No. 3
KM24
22 9/16”
RM36C
37 l/16”
29”
RM46, RM47
39 5/8”
32”
RM66, RM67
47 l/2”
41”
RM76, RM77
70 l/4”
59”
PROPER VENTING IS REQUIRED TO ENSURE BEST PERFORMANCE
UPPER VENT
/
I
VENTILATIOX
/
I
Fig. 4
