6. TROUBLESHOOTING
(Ice Maker Fails–Does Not Make Ice)
A. Check fuses or breaker supplying 120 volts AC to
refrigerator and check that RV is connected to power.
B. Check that ice level bail arm is in "down" position.
C. Check that the water line manual shutoff valve is
open.
D. Check that ice has not jammed the level bail arm.
FOR POSSIBLE ALTERNATE METHODS OF WINTERIZ-
ING, CONSULT THE OWNER'S AND OPERATOR MANUAL
FOR THE RECREATIONAL VEHICLE WATER SYSTEM.
WIRING
DIAGRAM
WIRING DIAGRAM FOR
ICE MAKER
