33
5.6 Removal of the door
This hinges are screwed onto the housing and
snapped in as well. Unscrew at first , then
unlock the hinge and the door by pushing the
lock notch.
Fig. 46
Fig. 47
5.7 Removal of the fascia
The operation panel can be loosened by remo-
ving two screws, when the door is opened. The
electronics at the RM(D) 8xx1 and RM(D) 8xx5 is
screwed into the panel from the inside.
Fig. 48
If the fridge is demounted, the operation panel
including the holding device can be loosened
very easily. It is only attached to the housing.
Fig. 49
