36
5.8 Flowcharts
Interior light does not
work
Interior light not pro-
grammed?
-> programm via service-
mode
Wiring not ok?
-> check wiring (connector
X111 or 114=door switch
input; X109= light output);
note polarity for LED light!
LED light module
defective?
-> exchange light module
MES / AES board
defective?
-> exchange main board
MES / AES
Repair & Maintenance
5.5
2.1
5.7
5.1
5.8
35
37
Table of Contents
Default Chapter
2
Table of Contents
2
1 Description of Model
4
Model Identification
4
Technical Data
5
Description of Refrigerator
6
Terminal Block
9
General
10
Explanation of Operating Controls
11
2 Components
12
Power Modules
12
Power Module RM 8Xxx1 (MES)
12
Power Module RM 8Xxx5 (AES)
12
Power Module RMD 8Xxx1 (MES)
13
Power Module RMD 8Xxx5 (AES)
13
Operating Principle
14
Temperature Sensor NTC
14
Burner Control Device T P810
14
Gas Valve GV100
15
Gas Burner
15
Interior Light and Door Lock
16
3 Wiring Diagrams
18
RM 8Xx0 / RMS 8Xx0
18
RM 8Xx1 / RMS 8Xx1
19
RM 8Xx5 / RMS 8Xx5
20
RM 8Xx5 with Electrical Door Lock
21
RML 8Xx0 / RMSL 8Xx0
22
RML 8Xx1 / RMSL 8Xx1
23
RML 8Xx5 / RMSL 8Xx5
24
RMD 8Xx1
25
RMD 8Xx5
26
4 Troubleshooting
28
Information on Failure Display and Trouble-Shooting
28
Status Messages on the Display
28
5 Repair & Maintenance
30
Entering the Service Mode
30
Entering Service Mode MES
30
Entering Service Mode AES
30
Displaying Software Versions of Power Module (RMD 8Xxx)
31
Sequence for Recognizing "Heating Element Defect
32
Controlling the Interior Light Via Door Switch
32
Recognising the Electrical Door Lock
32
Removal of the Door
33
Removal of the Fascia
33
Removal of the Interior Light and Door Lock
34
Flowcharts
36
Testplan MES
43
Testplan AES
44
6 Appendix
46
List of Gas Burners and Jets
46
Overview Software Changes
48
