Dometic RML 8550 Service Instructions

9
A = Plus heating element DC
B = Ground heating element DC
C = Ground electronics
D = Plus electronics
D+ = alternator signal
S+ =
AES -input-control signal
(solar charge regulato
2
1
2
1
1.5 Terminal block
Connections:
A = Ground heating element DC
B = Plus heating element DC
C = Ground electronics
D = Plus electronics
D+ = alternator signal
S+ =
AES -input-control signal
(solar charge regulator)
AB
D+
S+
CD
–
+
+
–
fahrzeugseitig
geräteseitig
RM 8xxx
RMD 8xxx
on the vehicle
on the appliance
Fig. 11
1
D+ S+
CD
-
+
on the vehicle
on the appliance
Fig. 12
A
+
-
B
2
Fig. 9
Fig. 10
