Description of model
3.4 Description of refrigerator
Operating controls
Freezer compartment
Post-evaporator for cooling compartment
Condensation water drain channel
Data plate
Vegetable bin
Door shelves
2
1
3
4
5
6
7
Fig. 3
Freezer compartment:
already frozen food (deep-frozen food)
Middle compartment:
Dairy products, convenience food
Bottom compartment:
Meat, fish, food for defrosting
Vegetable compartment:
Salads, vegetables, fruit
Top door shelf:
Eggs, butter
Middle door shelf:
Cans, dressings, ketchup, jam
Bottom door shelf (drinks compart-
ment): Drinks in bottles or bags
(1.5 ltr. max.)
B
A
C
D
E
F
G
1
6
3
7
4
2
5
B
A
C
D
E
F
G
