Dometic SeaStar - Sport Tilt Helm Mounting Template

3
2
✁
E L O H 1
) m m 7 7 ( . A I D " 3
) m m 5 . 2 8 ( " 4 / 1 - 3
) m m 5 . 1 2 ( " 5 8 . 0
1-27/32" (47mm)
S E L O H 3
) m m 8 ( . A I D " 6 1 / 5
2-3/8" (60mm)
29/32" (23mm)
2.57" (65mm)
E N I L T U O E G N A L F M L E H
) m m 5 . 0 2 1 ( " 4 / 3 - 4
) y l n o e c n e r e f e r r o f (
SPORT TILT HELM
MOUNTING TEMPLATE
If you must photocopy this mounting template for use, check ALL measurements
using a measuring device prior to using as a template.
NOTICE
