TEC60EV Installation
17
8.2 Securing the silencer
Observe the following instructions when installing the exhaust pipe:
• Do not create any sharp bends which will inhibit the flow of exhaust fumes.
• Align the manifold (fig. 6 1, page 4) (not included in the scope of delivery)
along the housing to ensure greater damping of vibration.
• Use the exhaust pipe extension (fig. 6 2, page 4) to divert the exhaust fumes.
➤ Secure the extension to the vehicle floor (fig. 6 3, page 4).
➤ Secure the silencer (fig. 6 4, page 4) as in one of the alternatives shown in
fig. 6, page 4 to fig. a, page 6.
8.3 Installing the tank and fuel supply line
Please observe the following instructions for the installation location (fig. b,
page 6):
• The tank bottom must be positioned at a maximum of 0.3 m below the bottom of
the generator.
• The top of the tank must not be higher than the top of the generator otherwise
the fuel will not be able to feed in.
➤ Lay the fuel line as straight as possible.
➤ Secure the tank.
8.4 Mounting the control panel
Please observe the following instructions for the installation location:
• Observe the length of the extension cable from the control panel to the
generator.
➤ Drill the holes as shown in fig. c, page 7.
➤ Insert the plug into the control panel.
➤ Screw on the control panel.
TEC60EV-I-16s.book Seite 17 Montag, 5. August 2019 2:17 14
