Disposal TEC60EV
20
9.3 Creating the priority circuit
You can create a priority circuit using a changeover relay whereby the external
voltage supply has priority over the generator, see circuit diagram (fig. f, page 9):
➤ Mount the changeover relay in a suitable position.
➤ Connect the wires following the circuit diagram (fig. f, page 9).
9.4 Connecting the float
➤ Connect the float from the tank to the float connection (fig. g 1, page 9).
9.5 Connecting the control panel
➤ Connect the control panel to the generator box using the extension cable pro-
vided on the plug for the control panel (fig. h 1, page 10).
10 Disposal
➤ Place the packaging material in the appropriate recycling waste bins wherever
possible.
M
If you wish to finally dispose of the product, ask your local recycling centre
or specialist dealer for details about how to do this in accordance with the
applicable disposal regulations.
22 Control panel extension cable connector
23 Control panel extension cable
24 Control panel
Item Description
1 User load
2 AG169 changeover relay
3Inverter
4 Mains
Item Description
TEC60EV-I-16s.book Seite 20 Montag, 5. August 2019 2:17 14
