8.1 Securing the generator
Note on installation location
• Make sure that no combustible objects are stored or installed near the air outlet
or the ventilation slots. A distance of at least 70 cm should be kept.
• For safety reasons, note the location of existing wiring harnesses, wires and other
components within the installation area, in particular those which are not visible,
when installing the generator (when drilling or screwing etc.).
• Leave a space of at least 70 mm between the generator hood and surrounding
parts so that sufficient space remains for cooling air to pass through.
• Prepare a sealed compartment against the vehicle interior which can also be insu-
lated against sound.
Attach exhaust openings to the floor.
➤ Mount the brackets to the casing and affix them with the screws (fig. 2, page 3).
➤ Position the casing in the desired area and attach it with the appropriate screws
(fig. 3, page 3).
➤ Insert the generator into the casing and screw it into place (fig. 4, page 4).
➤ Mount the casing flap and attach it with the pins (fig. 5, page 4).
DANGER! Danger of electrocution
Disconnect all power supplies when working on the generator.
CAUTION! Beware of injury
• The generator may only be installed by qualified personnel from a
specialist company. The following information is intended for
technicians who are familiar with the guidelines and safety precau-
tions to be applied.
• Improper installation of the generator can result in irreparable
damage to the device and put the safety of the user at risk.
• Always wear the recommended protective clothing (e.g. protective
goggles, gloves).
