TEC60EV Connecting the electrical power to the generator
19
Legend for electrical connections in fig. d, page 7
Legend for circuit diagram in fig. e, page 8
Item Description
1 Inverter terminals
2 Battery positive terminal
3 Battery negative terminal
Item Description
1 Starter motor
2 Motor coil
3 Oil level
4Choke
5 Ground connection
6 Battery charger
7 Alternator
8 Battery charger fuse connector
9 Engine connector
10 Internal control card
11 Inverter connector
12 Stepper motor connector
13 Engine stop connector
14 Inverter terminals
15 Control panel connector
16 Inverter
17 Alternator connector
18 Battery negative terminal
19 Battery positive terminal
20 Main switch
21 Stepper motor
