15Dominator Select Instruction Manual
19. User Operating Controls
05
06 07
01
02
03
04
Button Function
1. DOWN ARROW (Blue) Closes the door
2. DOWN ARROW LED (Blue) Illuminates when the door is closed and ashes when the door is obstructed on close or
stopped.
3. STOP (Red) Stops the door
4. UP ARROW (Green) Opens the door
5. UP ARROW LED (Green) Illuminates when the door is open and ashes when the door is open with the auto-close
timer running, obstructed on opening or stopped.
6. MODE (Yellow) Enables Load Diagnostics Mode
7. MODE STATUS LED (Yellow) Illuminates when in Diagnostics Mode
8. REMOTE CONTROL
STATUS LED (Red)
Flashes on remote lockout and ickers on remote control activity
9. ADJUSTMENT LED (Yellow) Flashes a certain number of times depending on the parameter being changed.
0809
