Dominator Select Instruction Manual2
Contents
1. Installation Safety Warnings! 3
2. Before you Begin 4
3. Tools Required 4
4. Kit Contents 5
5. Position 5
6. Fit the Opener 6
7. Bracket Position 6
7.1Wall Bracket Position: 6
7.2 Mounting the Wall Bracket: 6
7.3 Attach the Track to the Wall Bracket 6
8. Perforated Angle 7
9. Mounting Brackets and Arms 7
9.1 Mounting the Door Bracket: 7
9.2 Attaching the Arms 7
10. Optional Safety Beam Kit 8
11. Specifications 8
12. Setting Limits 9
12.1 Set the Limit Positions, adjust drive speed: 9
12.2 Clearing the Door Limit Positions 9
12.3 Re-proling the Door 9
13. Safety Testing 10
13.1 Test the Close Cycle 10
13.2 Testing the Open Cycle 10
13.3 Test the Manual Door Operation 10
14. Auto-Close 11
Installation Instructions
15. Coding a Transmitter 12
15.1 Storing the Transmitter Code 12
15.2 Installation of the Wall Mounted Transmitter 12
15.5 Remotely Coding Transmitters 12
15.3 Erasing All Transmitter Codes 12
15.4 Vacation Mode 12
16. Home Owner Safety Warnings! 13
17. Opener Safety & Security 14
17.1 Your Door CAN NOT be used when: 14
17.2 Your Door CAN be used when: 14
17.3 To Disengage the Opener: 14
17.4 To Re-Engage the Opener: 14
18. Operating your Opener 14
19. User Operating Controls 15
20. Troubleshooting 16
21. Maintenance 18
21.1 Door Maintenance 18
21.2 Battery Replacement 18
21.3 Battery Disposal 18
22. Appendix 19
A - Status Indication during Operating Mode. 19
B - Adjustment Mode Instructions 20
C - Adjusting Force Margins 20
D - Setting Limits via Transmitter 21
E - Setting the PET mode position 21
F - Setting up Tilt Door 22
23. Warranty 23
Home Owner Instructions
WARNING! IMPORTANT SAFETY INSTRUCTIONS
FOLLOW ALL INSTRUCTIONS SINCE INCORRECT INSTALLATION CAN LEAD TO SEVERE INJURY.
• before installing the drive, remove all unnecessary ropes or chains and disable any equipment, such as locks, not needed for
powered operation;
• before installing the drive, check that the door is in good mechanical condition, correctly balanced and opens and closes
properly;
• install the actuating member for the manual release at a height less than 1,8 m;
• install any xed control at a height of at least 1,5 m and within sight of the door but away from moving parts;
• permanently x the labels warning against entrapment in a prominent place or near any xed controls;
• permanently x the label concerning the manual release adjacent to its actuating member;
• after installation, ensure that the mechanism is properly adjusted and that the drive reverses when the door contacts a 40 mm
high object placed on the oor.
• necessary information for the safe handling of a drive weighing more than 20 kg. This information shall describe how to use the
handling means, such as hooks and ropes;
• the drive must not be used with a door incorporating a wicket door (unless the drive cannot be operated with the wicket door
open);
• after installation, ensure that parts of the door do not extend over public footpaths or roads.
• vertical doors and gates need an anti-drop feature or device;
• information if a hazardous part of the drive is intended to be installed at a height of at least 2.5 m above oor level or other
access level;
• except for horizontally moving pedestrian doors, ensure that entrapment due to the opening movement of the driven part is
avoided
