10. Optional Safety Beam Kit
10.1 Safety Beams
The Safety Beam Kit provides additional safety by preventing the door closing
when the beam is blocked by a car, child etc. When the Safety Beam Kit is
installed the Auto-close feature can be enabled if required.
a. To install the Safety Beam Kit, refer to the Safety Beam instruction supplied
with the kit.
b. After the beams are installed the beam alignment feature of the opener
can be used.
c. Turn power on to the opener.
d. Align the safety beams using the main light as a guide:
i. bright = aligned
ii. dull = not aligned or blocked
When the beam is aligned or if no beam is tted, continue with Setting Limits.
11. Specications
Technical Specications Select
DSO-1
Rated voltage range: 230V - 240Va.c.
Rated frequency: 50Hz / 60Hz
Rated power input: 165W
Door opening:
Maximum Door Area:
Maximum Door Weight:
Door must be well balanced and able to be operated by
hand, as per warranty conditions and AS/NZS 4505:2012
15m
2
140kg*
Minimum headroom 57mm
Rated Operating Time 4 mins
Rated Temp +5
o
C to +40
o
C
Short Term Peak force: 700N
Door travel speed (mm/sec) 140mm
Rated load 400N
Nominal force 200N (20kg)
Receiver type Multi-frequency UHF FM
Receiver code storage capacity 64 X 4-button Transmitters
Transmitter battery CR2032 (3 Volts)
Courtesy light LED (Light Emitting Diodes)
Network connectivity Network ready
(requires optional smart phone control kit)
* Gross door weight, including all ttings
Note: During the open and close cycles, intermittent operations may occur in areas which experience very strong
winds. The strong wind puts extra pressure on the door and tracks which may in turn intermittently trigger the safety
obstruction detection system.
