Domino DPX3500 User Manual

EPT076596 Issue 1 – March 2022
38
System Specifications
Unit: DPX3500 (Indoor use only)
Housing material: Stainless Steel
IP rating: IP56
Capacity: 450m
3
/h (265cfm)
Weight (Including filters): 172kg (379lbs)
Weight (without filters): 112kg (247lbs)
Motor: Centrifugal Fan
Output: 2200w
Electrical supply: 100-230V (+/-10%)
Hertz: 47-63Hz
Full Load Current: 20.0A
External fuses at mains power supply: Fast blow B/C type
Recommended rating for fuses:
110V – 25A
230V – 20A
No of phases: 1
Noise Level: Below 70dB (A)
(at typical operating speed)
Size:
Metric
(mm)
Imperial
(inches)
Height
980
39
Depth
831
33
Width
630
25
Filters:
Filter
Type
Surface area
Efficiency
F6 Pre-
filter bag
5.0m
2
ISO ePM10
60%
F8 Pre
filter
30.0m
2
ISO ePM10
75%
F9 Pre
filter
30.0m
2
ISO ePM10
90%
Main filter
3.0m
2
99.997% @
0.3micron
Main Filter (Gas section)
Filter
Type
Carbon type
Amount
Main filter
(Gas)
Activated
carbon
34kgs
Environmental operating range:
Temperature: +5
o
C to +45
o
C
Temperature range for transport: +5
o
C to +70
o
C
Humidity: Max 80% RH up to 31
o
C
Max 50% RH at 40
o
C
Pollution degree: 2
Supply voltage fluctuations: ±10 %
Maximum altitude for operation: <2000 m
Factory air changes per hour: minimum 6
Wiring schematic available upon request
Spares parts list available upon request
