The USB MIDI/Audio interface can connect the module with any computer, mobile phone, iPad or devices with MIDI processing or USB Audio for data transmission.
The USB MIDI is usually used for music creation, production, and performance, such as using DAW (Digital Audio Workshops) audio software or music education,
real-time performance, music control, and audio processing software that supports USB MIDI.
The USB AUDIO is usually used for USB audio output and the number of channels is 14. When connecting DAW, you may create a 14-channel output (When creating
channels in DAW, the names for the drums are shown by default).
The USB interface supports Type-C USB ports only.
Sample Rate: 44.1 kHz
Bit Depth: 16 bit
Signal-to-Noise Ratio, SNR: 96dB
Signal Latency: 5-10ms
Dynamic Range: 96dB
Driver Installation:
Windows operating systems:
• When connecting to a computer, it may be required to install ASIO4ALL driver in your Windows operating system to guarantee optimal performance and
compatibility.
• Before using the equipment, please download and install the ASIO4ALL driver of the latest version. You may find the download link on the official website of
ASIO4ALL.
Mac operating systems:
• No additional driver is required for Mac users. The system will automatically identify and configure devices to guarantee smooth usage experience.
If you have any driver installation problem when using your Windows operating system, please refer to the detailed descriptions on the ASIO4ALL website or
contact our technical support team for help.
❹
USB MIDI/AUDIO interface
Mian Out L
Mian Out R
Snare
Hi-hat
Tom 1
Channel 1
Channel 2
Channel 3
Channel 4
Channel 5
Tom 2
Tom 3
Tom 4
Kick
Crash 1
Channel 6
Channel 7
Channel 8
Channel 9
Channel 10
Crash 2
Ride
Backing L
Backing R
Channel 11
Channel 12
Channel 13
Channel 14
❶
Main OUT
Output to Drum Amplifier, Monitor, Mixer and connect R and L(MONO) as right and left channels; L(MONO) is equipped with MONO audio output to combine left and
right channel audio signals and output them to one output interface.
Specification: 6.35mm TS
❷
MIDI OUT
MIDI (Musical Instrument Digital Interface) output port. It transmits MIDI data to other MIDI devices, such as synthesizer, sequencer, or computer for music
control and data transmission.
Specification: MIDI USB cable
❸
SD CARD interface
Micro SD, Micro SDHC, and Micro SDXC; please note put the face of the SD Card up when inserting and withdrawing it to prevent unnecessary damages. (The SD
card is not included in the Module. SD card format: FAT32)
03
