Connections & Controls
●Easy Controls, Wide Flexibilities
The Dynamic Wah features an easy-to-
use four-knob tone control: SENS (filter
intensity), RES (filter sharpness),
DECAY (filter frequency resting time)
and RANGE (filter frequency range) for
using in different scenarios or with
different instruments. Each knob gives
you a wide control range.
●Carefully Selected Components
The Dynamic Wah is designed and built
with carefully selected components to
ensure best sound quality and road
performance. The solid Aluminum-alloy
chassis ensures touring reliability, and
True Bypass design gives you a
transparent tone.
Features
●Compact envelope filter pedal with
fast tracking and high accuracy
●100% analog circuit
●Wide range tone controls for creating
your own wah sound
●True bypass provides transparent
tone
●LED indicator shows the working
state
●Enduring, light-weighted Aluminum-
alloy chassis
a
b
c
d
e
Specifications
Power Requirement: 9V DC center
negative
Current Consumption: 10mA
Dimensions: 42x93.5x52mm
Weight: 230g
a
e
f
b
h
g
f
DC 9V Jack:
For power supply, use a 9-volt DC
regulated by AC adapter, 500mA
(plug polarity is positive on the barrel
and negative in the center).
SENS Knob:
Controls the sensitivity.
RES Knob:
Controls the filter sharpness.
DECAY Knob:
Controls how fast the filter frequency
falls back to the resting point.
RANGE Knob:
Controls the filter frequency range.
Input Jack:
1/4” mono audio jack, for connecting
guitar.
Output Jack:
1/4” mono audio jack, for connecting
to an amplifier.
Footswitch and LED:
Tap to switch the unit on/off. The
LED will lit up when the effect is on.
h
c
d
www.donnerdeal.com
