Connections & Controls
DC IN POWER JACK:
For supplying LED only. Use a 9-volt
DC regulated by AC adapter, 500mA
(plug polarity is positive on the barrel
and negative in the center).
LEVEL KNOB:
Controls the output level.
RETURN JACK:
1/4” mono audio jack, for connecting
amp’s FX loop send jack.
MINIMUM FOOTSWITCH AND LED:
Tap the footswitch to immediately set
amp output to minimum. In this case,
the LED will lit up.
Note: connecting to amps with serial
FX loop is recommended.
SEND JACK:
1/4” mono audio jacks, for connecting
amp’s FX loop return jack.
●No Power Supply Needed
You don’t need an extra power supply
for the tiny unit: connect to your amp’s
FX Loop jacks, set a level and done – or
tap the footswitch to immediately turn
the out level to minimum. The power
jack is for supplying LED onboard only.
●True Bypass
The EMO-AMP Controller features true
bypass design which keeps your sound
pristine.
●Carefully Selected Components
The EMO-AMP Controller is designed
and built with carefully selected
components to ensure best sound
quality and road performance. The solid
Aluminum-alloy chassis ensures using
reliability.
Features
●Convenient compact size
●Easy-to-use passive attenuator
●True bypass
●LED indicator shows working state
●Set output level to minimum
immediately by tapping MINIMUM
footswitch
a
b
c
d
e
Specifications
Power Requirement: 9V DC center
negative
Current Consumption: 10mA
Dimensions: 42x93.5x52mm
Weight: 220g
www.donnerdeal.com
MINIMUM
Passive Attenuator
Return
Send
a
b
c
d
e
d
