Connections & Controls
●Carefully selected components
The Tutti Love pedal was designed and
manufactured with quality components
to ensure exceptional sound and sturdy
performance. The aluminum alloy
casing ensures touring reliability, and
the True Bypass circuitry gives you a
transparent tone.
Features
●Convenient compact size
●True Bypass
●Rich, natural analog chorus
●True bypass provides transparent tone
●Three knob configuration for flexible
sound character
●Reliable aluminum alloy casing
a
b
c
d
e
Specifications
Power Requirement: 9V DC center
negative
Current Consumption: 11mA
Dimensions: 42x93.5x52mm
Weight: 230g
a
c
d
b
www.donnerdeal.com
f
DC 9V Jack:
For power supply, use a 9-volt DC
regulated by AC adapter, 500mA (plug
polarity is positive on the barrel and
negative in the center).
LEVEL Knob:
Adjusts the chorus volume.
DEPTH Knob:
Adjusts the chorus sound depth.
RATE Knob:
Adjusts the chorus speed.
INPUT Jack:
1/4” mono audio jack, for connecting
instrument.
OUTPUT Jack:
1/4” mono audio jack, for connecting
to an amplifier.
Footswitch and LED:
Tap to switch the unit on/off. The LED
will lit up when the effect is on.
f
g
e
g
g
