Connections & Controls
●Carefully selected components
The Yellow Fall pedal was designed and
manufactured with quality components
to ensure exceptional sound and sturdy
performance. The aluminum alloy
casing ensures touring reliability, and
the True Bypass circuitry gives you a
transparent tone.
Features
●Convenient compact size
●True Bypass
●Rich, clear, natural analog delay
●Three knob configuration for flexible
sound character
●Reliable aluminum alloy casing
a
b
c
d
e
Specifications
Power Requirement: 9V DC center
negative
Current Consumption: 36mA
Dimensions: 42x93.5x52mm
Weight: 230g
a
c
d
b
www.donnerdeal.com
f
e
f
DC 9V Jack:
For power supply, use a 9-volt DC
regulated by AC adapter, 500mA (plug
polarity is positive on the barrel and
negative in the center).
ECHO Knob:
Adjusts the delay level.
F.BACK Knob:
Adjusts the amount of feedback
(number of repeats).
TIME Knob:
Adjusts the delay time from 20ms to
620ms.
INPUT Jack:
1/4” mono audio jack, for connecting
guitar.
OUTPUT Jack:
1/4” mono audio jack, for connecting
to an amplifier.
Footswitch And The LED:
Tap to switch the unit on/off. The LED
will lit up when the effect is on.
g
g
g
