INSTALLATION INSTRUCTIONS
A
THIS APPLIANCE IS
NOT
INTENDED
FOR
USE
BY
YOUNG
CHILDREN
OR
INFIRM
PERSONS WITHOUT SUPERVISION.
PLEASE ENSURE
THAT
YOUNG
CHILDREN
ARE
SUPERVISED
TO
ENSURE
THEY
DO NOT
PLAY WITH THE
APPLIANCE.
Ideally
,
as
with
all
pool equipment
,
the
controller should be installed
out
of
direct weather.
CONTROLLER
MOUNTING
Find
a
suitable location
to mount
the control box.
The controller should be
no
closer than
3
metres
from
the
water's
edge,
at
a
minimum
BOOmm
above
ground
level. The
power
cable is
1.8m
long
and should be
plugged directly
into
a
general
power
outlet,
not
into
an
extension lead.
Fix
the
mounting
bracket
to
a
solid
structure
with
the
screw
and wall
plug
kit
provided.
Slide
the controller
on,
locking
it
into
place.
Adjust
the
screws on
the back
of
unit
to
ensure a
snug
fit.
To
remove
unit,
lift
and
gently
pull
away
from
mounting
bracket.
Mount
the
pump
and
Sanitiser
according
to
the
manufacturer's
instructions.
POWER OUTPUT
CONNECTIONS
The
240VAC
Output
Sockets
are
for
eguipment
to
be controlled via the
AQUATEK
controller. Each
socket
can
be
assigned
via the
menu
and/or
app.
The maximum combined load
for
both
sockets
on
the
master
controller,
is
9.9
AMPS
at
2370W.
HEATER
CONTROL
Set
the heaters
temperature
limit
to
maximum
[40°C],
The heaters internal control
will
be
interrupted,
to turn
off
heating.
The heater interlock cable
connects to
the
green
socket
marked
INT
which switches
on
[closes]
the
voltage
free
ND/C
relay
contacts
when the heater is
to
be turned
on.
The heater end
of
the interlock cable
connects
in
series
with
the
heater's
pressure/flow
or
fireman's
switch.
Contact
the
heater
manufacturer for
the best location
to connect to.
The heater interlock is
for
extra
low-voltage
[MAX
24V
at
lAmp]
switching only.
Note:
If
the
heater's
flow
or
pressure
switch circuit is
2dOVac,
an
external
relay
[KITIO]
which
can
be
purchased
separately
,
is
to
be connected
by
a
licensed
electrician.
If
the heat
pump/gas
heater is
equipped
with
a
"Demand Heat"
function,
the heater
interlock cable
will
be connected into the
socket
labelled
as
"Pump
Call".
The
controller
will
over-ride the
filter
pump
when
flow
is called
for
by
the heat
pump
which monitors the
temperature
within
its
own
defined
run
times.
Connect
the
heater cable
from
the controller
output
to
the
heater's
connection
point.
Check
with
heater
manufacturer for
correct
interlocking
procedure.
Note:
If
the
heater's
flow
or
pressure
switch circuit is
2dOVac,
an
external
relay
[KITH]
which
can
be
purchased
separately
,
is
to
be connected
by
a
licensed
electrician.
VALVES
The
AQUATEK
has
4
valve
actuator
sockets
for
the
controlling
of
solar
heating,
water
features,
pool/spa
water
flow,
and
In
Floor
cleaning.
Note:
If
wiring
your
own
supplied
valve,
ensure
the wires
are as
follows:
[from
left
to
right]
White,
Red then Black. The red and white
are
for
direction control and black is
the
common.
Ensure
the switch
on
the valve
actuator
is switched
to
an
ON
position.
Refer
the valve instructions
for
mounting
requirements,
cam
adjustments
etc.
Maximum
power
for
the
VALVE
output
is
24VA.
AQUATEK
User
Manual
VI.
