 J6 – Safety Beams – Pins 7 to 10
 Activates the door except when in the closed position
 24 VAC power to safety beam module
 Red LED is on when active
 J5 – Inner and Outer Sensors
 Separate 24 VAC connections for sensor power
 Inner Sensor
o Activates door except when off or in night mode
o Green LED is on when active
 Outer Sensor
o Activates door except in off, one way, or night mode
o Green LED is on when active
 Safety
o Activates the door except when in the closed position
o Red LED is on when active
 J7 – Special Modes
 Emergency Open
o Activates the door during all modes
o Green LED is on when active
 Ratchet
o Activates door and stays open until ratchet is pressed again
o Does not activate during off, one way, or night mode
o Green LED is on when active
 Activation
o Activates the door during all modes
o Green LED is on when active
 Breakout
o Stops door motion
o Software selectable polarity (NO/NC)
o Red LED is on when active
 Night Mode
o Disables inner and outer sensors in closed position
o Door activates with emergency open and activation input only (pin 2 or 6 of J7)
o Yellow LED is on when active
 J8 – Lock
 Pins 1 to 6 are used to control the DC One lock
 Lock voltage is selectable between 12 and 24 volts with toggle switch
 See wiring diagrams for detailed information
CHECK TO ENSURE THAT ALL IS CLEAR AND READY TO OPERATE!PRESS THE TEST BUTTON ON THE
CONTROLLER. THE DOOR WILL MOVE THROUGH A LEARN CYCLE THEN REST IN THE CLOSED POSITION.
IF THE DOOR DOES NOT REST IN THE CLOSED POSITION GO BACK TO THE PROGRAMMING MENUS AND
CHANGE HANDING FROM LEFT TO RIGHT

Door Controls DC-ONE V3 Specifications

General

Brand	Door Controls
Model	DC-ONE V3
Category	Controller
Language	English
