DoorHan DS Series User Manual

1818
FOR THE DOCK LEVELER DSI
Table 1
Pos. Dock leveler length, mm
1
Dock leveler
width, mm
2 000 2 500 3 000 3 500 4 000
2 000 DSI2251 DSI25251 DSI3251 DSI35251 DSI4251
2 200 DSI22251 DSI252251 DSI32251 DSI352251 DSI4251
2 400 DSI22451 DSI252451 DSI32451 DSI352451 DS4251
2
Usage of
folding legs
(pos. 4, 5)
DSI22501/DSI22502 DS35253/DS35254
Table 2 (permissible load 6 000 kg, the lip 500 mm)
Pos. Dock leveler length, mm
1
Dock leveler
width, mm
2 000 2 500 3 000 3 500
2 000 DSI2252 DSI25252 DSI3252 DSI35252
2 200 DSI22252 DSI252252 DSI32252 DSI352252
2 400 DSI22452 DSI252452 DSI32452 DSI352452
Table 2 (permissible load 10 000 kg, the lip 500 mm)
Pos. Dock leveler length, mm
1
Dock leveler
width, mm
2 000 2 500 3 000 3 500
2 000 DSI2252-10 DSI25252-10 DSI3252-10 DSI35252-10
2 200 DSI22252-10 DSI252252-10 DSI32252-10 DSI352252-10
2 400 DSI22452-10 DSI252452-10 DSI32452-10 DSI352452-10
Table 2.1 (permissible load 6 000 kg, the lip 1 000 mm)
Pos. Dock leveler length, mm
1
Dock leveler width,
mm
2 500 3 000 3 500
2 000 DSI25212 DSI3212 DSI35212
2 200 DSI252212 DSI32212 DSI352212
2 400 DSI252412 DSI32412 DSI352412
Table 2.1 (permissible load 10 000 kg, the lip 1 000 mm)
Pos. Dock leveler length, mm
1
Dock leveler width,
mm
2 500 3 000 3 500
2 000 DSI25212-10 DSI3212-10 DSI35212-10
2 200 DSI252212-10 DSI32212-10 DSI352212-10
2 400 DSI252412-10 DSI32412-10 DSI352412-10
GENERAL FOR SERIES DS AND DSI
Table 3
Pos. Lip length, mm
1
500 mm 1 000 mm
unsegmented 3-segmented 5-segmented unsegmented 3-segmented
Dock leveler width, mm
2 000 DS16.3 DS4.3 DS10.3 DS13.3
2 200 DS17.3 DS5.3 DS11.3 DS14.3 DS2.3
2 400 DS18.3 DS6.3 DS12.3 DS15.3 DS3.3
