DoorHan DS Series User Manual

2020
STEEL CASING EXTERNAL INSTALLATION OF THE HYDRAULIC POWER PACK
Pos. Article Designation Amount
1 OE.DL17.1 Casing cover 1
2 OE.DL17.2 Casing base 1
3 DHA V-shaped anchor bolt assembly 12 x 120 mm 4
SETS FOR HYDRAULIC DRIVE EXTERNAL INSTALLATION
Dock leveler with telescopic lip, the dock leveler length L3 500
Pos. Article Designation Amount
1 OE.DL17
Metal casing for outdoor installation of
hydraulic drive
1 pcs
2 5700HD110 AB90-0 Hydraulic hose L = 5 700 mm 4 pcs
Dock leveler with telescopic lip, the dock leveler L>3500
Pos. Article Designation Amount
1 OE.DL17
Metal casing for outdoor installation of
hydraulic drive
1 pcs
2 7900HD110 AB90-0 Hydraulic hose L = 7 900 mm 4 pcs
