Operation Section
-47-
Tilt Control
1. Mast Tilt Forward - Push the lever
FORWARD smoothly to tilt the mast forward.
2. Mast Hold - When the lever is released it will
return to the HOLD or center position. Tilting
action will stop.
3. Mast Tilt Back - Pull the lever BACK
smoothly to tilt the mast backward.
Sideshift Attachment Control (If
Equipped)
1. Sideshift Left - Push the lever FORWARD to
shift the carriage to the left.
2. Sideshift Hold - When the lever is released it
will return to the HOLD or center position.
Sideshifting action will stop.
3. Sideshift Right - Pull the lever BACK to shift
the carriage to the right.
